Connect the controller power line (DC24V) with the Direct Current Power Supply. The controller is 7 Cun high definition color screen. The screen size is 215mm x 152mm

Opertation:

Set the parameter after installing, then fresh the data. Press the “Start” button to start the winding machine

Notes:

1. When refresh the data, all parameters of the meter counters are refreshed (including common parameters and multi-function parameters)

2. Only the first time connect the controller with the meter counters, the refresh is needed. Once the parameters of controller are changed, the parameters of meter counters will be changed accordingly.
